PAGURO 12000 V-10 KW-2000÷3000 RPM

Price excludes 5% UAE VAT

REQUEST PRICE

Specifications

  • Remote control with LCD display.
  • Hour meter, load indicator, frequency / engine rotation speed.
  • Automatic shut-off for low oil pressure and / or overtemperature.
  • Quick connector and 15 meters of cable.
  • Automatic start.
  • SOUNDPROOFING CAPSULE – Acoustic insulation with reinforced composite fiberglass capsule and coating in high-density sound-absorbing material. The capsule, composed of two upper and lower parts, allows installation even in narrow spaces.Double anti-vibration system, inside 4 soft supports and 4 external semi-elastic supports.

PAGURO MARINE GENERATORS

Features
  • FLEXIBLE AND SILENT PERFORMANCE
  • SILENT
  • LIGHTWEIGHT AND COMPACT
  • SAFE

ALTERNATOR
ALTERNATOR MANUFACTURER V.T.E. SRL – ITALIA
ALTERNATOR TYPE PERMANENT MAGNETS
CONTINUOUS ELECTRICAL POWER KVA 12 KVA
CONTINUOUS ELECTRICAL POWER KW 10 KW
BATTERY CHARGE 12 V – 8 A
NUMBER OF PHASES 1
PEAK CURRENT 80 A
ALTERNATOR COOLING AIR



ENGINE
ENGINE MANUFACTURER LOMBARDINI MARINE, ITALIA
ENGINE MODEL LDW 1003
CYLINDERS NR. 3
ROTATION SPEED 2000 rpm and 3000 rpm
CONSUMPTION OF GAS OIL 0,35 lt./KW/h
COOLING SYSTEM FRESH WATER WITH HEAT EXCHANGER
STARTING SYSTEM ELECTRIC A 12 V
REMOTE CONTROL Yes
COOLING PUMP SELFPRIMING



GENERAL SPECIFICATIONS
DIMENSIONS (mm) 770 X 460 X 620H
WEIGHT (CAPSULE INCLUDED) (Kg) 165
ELECTRONIC WEIGHT CONTROL (Kg) 15
NOISE LEVEL dB 50 – 53 dB(A)
