Airpax Hydraulic Magnetic Circuit Breake Lever 10A Part No:14.736.10

Airpax Hydraulic Magnetic Circuit Breake Lever 10A

Designed on purpose for the marine environment. In case of heavy overload (i.e.: short circuits), the circuit breaker disconnects instantaneously; for overloads up to 50% it maintains the contact for few seconds so, in case it is due to a chance event, it has time to return within the limits without interrupting the power supply. In case of short circuit, the switch cannot be reactivated until the problem is solved. – Toggle handle circuit breaker – Toggle actuator, IAG series, universal 12/220 V, front recess in the panel, 16-mm Ø. – Flat flush toggle circuit breaker for horizontal or vertical mounting – Flat actuator with flush toggle, coloured light indicator for OFF position. IEGB series, universal 12/220 V, front recess in the panel 32×19-mm.
